7" videointercom - SE7PG

SE7PG

LIGNE: Sette
TECHNOLOGIE: deux fils Pluggy
CATEGORIE: Poste intérieur Video

Colour hand-free videointercom, digital 2 wire Pluggy technology, with LCD 7" screen in Sette line. OSD menu interface, soft touch buttons and LED's icons for door opening, conversation, intercommunication and additional functions. Signalling LED's for open door and bell exclusion. Compatible with 1SEPG videokits.

Soon available.

PLUS

Pluggy videokit  - 1SEPG

1SEPG

LIGNE: Alba,Sette
TECHNOLOGIE: deux fils Pluggy
CATEGORIE: Vidéo kit

Colour 1-way videokit in digital 2 wire Pluggy technology. Ready and complete for the installation, it is composed by dedicated elements: 7" monitor in Sette line + video panel in Alba line with wide-angle camera ready up to 4 call buttons + power supply unit.

Made in Italy, expandible up to 4 uses by integrating it with single monitor art. SE7PG.

Soon available.

PLUS

H.265 8MP (4K) IP CAMERA - TVT65NK

TVT65NK

LIGNE: Farfisa for Security
TECHNOLOGIE: CCTV IP
CATEGORIE: CCTV caméra

Barnd new IP ONVIF camera with motorized varifocal 3.3-12mm lens suitable even for outdoot installation (IP66). Thanks to STARVIS da 8 Megapixel (4K) sensor, it allows to capture highest definition (UHD) pictures, while the new H.265 compression allows to transmit video over network with reduced bandwight request. It has 3 independent video streaming that can be adjusted for various applications, as well as privacy areas, e-mail sending up on even, motion detection and intelligent video analisys with "deep learning" (Perimeter intrusion detection, face detection, line crossing and left object detection) are available. video capture can be done very well even in night conditions thanks 30 IR led and ICR filter removable. Local recording is also possible by uSD port for removable memory card. Other ports: alarm 1in / 1 out, BNC output for service monitor connection, audio 1 input / output. The remote adjustment of the motorized lens can be done by web page or by NVR, as well as the configuration of all the video parameters: it is suggested to be used in combination with NVR442K, NVR882K and NVR1682K that support plug&play installation.

PLUS

3.5" graphic display - DD2140AB

DD2140AB

LIGNE: Alba
TECHNOLOGIE: Deux fils - DUO,SANS FILS - MYCOM
CATEGORIE: Plaque de rue Audio,Plaque de rue Video

3.5 “graphic LCD display module with 4 backlit function keys. The electronic index function for displaying and calling system users is integrated. It must be connected to the audio module CA2124AB or audio-video CV2124AB (for Duo System) or AB3G (for MyCom systems) and can also be combined with the PD2100AB keyboard module. Capacity is 1000 users, to each of which the address of the internal device of the system must be associated in case of Duo System systems, or the code relative to the telephone number to call, in MyCom systems. If associated to a PD2100AB keypad, each user can also be assigned a password to activate one or more of the possible activations. In addition, the “Alias” feature is included in the phonebook.

PLUS

Coil antenna for Solvo -TL2000

TL2000

LIGNE: Solvo
TECHNOLOGIE: Deux fils - DUO
CATEGORIE: Accessoir

Accessory coil antenna for Solvo door panel to be inserted into Solvo door station. It allows the compatibility with Solvo door panel and the hearing aid for hearing impaired users.

PLUS

4+1 ZheroS monitor - ZH1151W

ZH1151W

LIGNE: ZHero
TECHNOLOGIE: câblage reduit
CATEGORIE: Poste intérieur Video

4" Videointercom of ZHero series, ZHeroS model, suitable for 4+1 reduced wiring with electronic call systems. Ideal even for complex estates with high number of users and thanks to the essential and top quality design, it is suitable to any environment. Very thin and surface mounting. Icons for door open and bell exclusion notification. 2 buttons for answering and door lock release; 2 buttons for monitoring function to main or additional external door station activation or dry contact. Additional functions to be properly wired. Intercommunicating service is not available.

PLUS

Table adaptor for Sette monitor -TA4260

TA4260

LIGNE: Sette
TECHNOLOGIE: Deux fils - DUO
CATEGORIE: Accessoir

Table adaptor for Sette series monitors. Made in transparent / white methacrylate, it allows the practical usage of the videointercoms resting on a table. Provided with 2.4 m cable.

PLUS

Basic kit myCom Alba3G - KIT 1MCABS

KIT 1MCABS

LIGNE: Alba
TECHNOLOGIE: SANS FILS - MYCOM
CATEGORIE: Kit Audio

Kit 1MCABS includes all necessary material for the installation, surface mounting, of a door panel 3G/GSM up to 4 buttons. Articles inside are AB3G door panel, AB91 rain shelter and PRS210 power supply together with AB61 and AB71 front and module frames and AB20 and AB21.

It requires a nano SIM only, to make calls by using GSM net. Door panel can be further extended by using button CT2138AB modules or digital keypad PD2100AB module, up to max 200 calls. Each call button can be associated to up to 3 different phone numbers to be called in sequence. The item is provided with 2 relays that can be activated independentely and 2 inputs that can be used as alarm, o for other functions. CLIP function allows to activate one of the relays by sending the call to the door panel. The item can be programmed through the web cloud interface, through app or by connecting to a PC and using a software that can be downloaded free from the website, or through text command via SMS.

PLUS

Kit myCom Alba3G flush mounting -KIT1MCAB

KIT 1MCAB

LIGNE: Alba
TECHNOLOGIE: SANS FILS - MYCOM
CATEGORIE: Kit Audio

Kit 1MCAB includes all necessary material for the installation, flush mounting, of a door panel 3G/GSM up to 4 buttons. Articles inside are AB3G door panel, SC1 back box and PRS210 power supply together with AB61 and AB71 front and module frames and AB20 and AB21.

It requires a nano SIM only, to make calls by using GSM net. Door panel can be further extended by using button CT2138AB modules or digital keypad PD2100AB module, up to max 200 calls. Each call button can be associated to up to 3 different phone numbers to be called in sequence. The item is provided with 2 relays that can be activated independentely and 2 inputs that can be used as alarm, o for other functions. CLIP function allows to activate one of the relays by sending the call to the door panel. The item can be programmed through the web cloud interface, through app or by connecting to a PC and using a software that can be downloaded free from the website, or through text command via SMS.

PLUS

Kit myCom Alba3G - KIT 1MCPDAB

KIT 1MCPDAB

LIGNE: Alba
TECHNOLOGIE: SANS FILS - MYCOM,Contrôle d'accès
CATEGORIE: Kit Audio

Kit with MyCom technology Alba 3G composed by: AB3G, access control keypad PD2100AB, Alba accessories AB72, SC2, AB92,AB20, 2xAB21, AB62 and power supply PRS210.

PLUS
