1-way audio kit, 1+1 technology, made up of Exhito EX311 intercom, Slim line door panel and PRS210ED power supply.
The door panel, made in stainless steel, is characterized by very small dimensions especially in width and the possibility of inserting RFID reader module art. FP2000. Surface mounting, equipped with rain shelter.
1+1 technology.
Video external door station of Solvo series, for DUO digital system. A single element with keypad 16 buttons, 4 status icons and alphanumerical LCD, it allows to make and dial calls in DUO systems with up to 20000 users. 3 white led for camera. It can accomondate FP2000 RFID reader or Vigik device. Compatible with TL2000 audio loop for impaired people.
For surface mounting 290C/0 back box is available.
Door lock operation time: max 10 sec.
Power supply from DUO bus.
Audio external door station of Solvo series, for DUO digital system. A single element with keypad 16 buttons, 4 status icons and alphanumerical LCD, it allows to make and dial calls in DUO systems with up to 20000 users. It can accomondate FP2000 RFID reader or Vigik device. Compatible with TL2000 audio loop for impaired people.
For surface mounting 290C/0 back box is available.
Door lock operation time: max 10 sec.
Power supply from DUO bus.
Set of products that are used to connect a crafted or customized (third-party, for example brass) door panel with Hero electronics. 1 or maximum 2 XT2932U must be added. A maximum of 64 calls can be handled.
Kit 1MCAB4 includes all necessary material for an intercom installation 4G/GSM technology up to 4 calls. Articles inside are AB4G door panel, SC1 back box and PRS210 power supply together with AB61 front frame and AB71 module frame and AB20 and 2 pcs AB21. Flush mounting,
It requires a nano SIM only (Nano SIM, LTE, VoLTE), to make calls by using GSM net. Door panel can be further extended by using button CT2138AB modules or digital keypad PD2100AB module, up to max 200 calls. Each call button can be associated to up to 3 different phone numbers to be called in sequence. The item is provided with 2 relays that can be activated independentely and 2 inputs that can be used as alarm, o for other functions. CLIP function allows to activate one of the relays by sending the call to the door panel. The item can be programmed through the web cloud interface, through app or by connecting to a PC and using a software that can be downloaded free from the website, or through text command via SMS.
Note: for North and Central America please ask Farfisa Technical Service Department for the appropriate item code.
Kit with MyCom technology Alba 4G composed by: basic door panel module AB4G, access control keypad PD2100AB, Alba accessories: module frame AB72, back box SC2, rain shelter AB92, button cover AB20, button 2xAB21, front frame AB62 and power supply PRS210.
Note: for North and Central America, please ask Farfisa Technical Service Department for the appropriate item code.
Kit 1MCABS4 includes all necessary material for an intercom installation 4G/GSM technology, up to 4 calls. Articles inside are AB4G door panel, AB91 rain shelter and PRS210 power supply together with AB61 and AB71 front and module frames and AB20 and 2 AB21. Surface mounting.
It requires a nano SIM only (Nano SIM, LTE, VoLTE), to make calls by using GSM net. Door panel can be further extended by using button CT2138AB modules or digital keypad PD2100AB module, up to max 200 calls. Each call button can be associated to up to 3 different phone numbers to be called in sequence. The item is provided with 2 relays that can be activated independentely and 2 inputs that can be used as alarm, o for other functions. CLIP function allows to activate one of the relays by sending the call to the door panel. The item can be programmed through the web cloud interface, through app or by connecting to a PC and using a software that can be downloaded free from the website, or through text command via SMS.
Note: for North and Central America please ask Farfisa Technical Service Department for the appropriate item code.
External antenna, complete with coaxial cable and proper connector in MyCom systems (GSM 4G). It's useful in all the situations when the signal is weak. The bracket is not included.
Interface board that allows to connect any analog entry door panel to Alba or Hero modules. Each board allows to connect max 32 buttons and it is possible to connect a further board in cascade.
Main module for entry door panel in Mycom systems with 4G technology. In Alba range, it works with Alba installation elements. Standalone or in composition with expansion modules, if installed with power supply only, it allows a complete and reliable system for access control with no cables and no distance limits.
Audio module on Alba range with electrical door speaker integrated in 4G technology and ready for max 4 calls in double button mode. The call is made by the external panel by using the mobile net (a nano SIM card is necessary but not included) and can be sent to max 3 fixed or mobile telephone numbers, programmable in sequence for each call button. Up to 2 ouputs through the provided relays can be managed separately, for example for a pedestrian door and a gate for vehicles. This item is the ideal solution for an installation without distance limit between external panel and internal station, absolutely without cabling. It can be connected through Alba bus to CT2138AB button module, with total 68 buttons or through digital keypad PD2100AB and/or display DD2140AB for up to 200 users. 2 alarm entrances. Function "calling number recognition for door lock opening (CLIP) through call or SMS for all the users already inside Conctacts plus further 200 telephone numbers, alarm management and NAC function (signal for attempted use clip function by a non-authorized user).
Programming is made through web interface, app, PC with MyComManager software or SMS. Lighting signals for conversation status indications, relay activation, subscription to telephone net, signal intensity. To be completed with AB20 or AB21, depending on the number of calls to use.
