TECHNOLOGIES

CATALOGUE >

TECHNOLOGIES (18)

two wires - Xentry

The new Xentry line could be the best solution for your home security! Yes, because it integrates IP technology with 2-wire cabling, guaranteeing the advantages of IP and 2-wire simultaneously!

Xentry consists of two single-family video kits that differ from the entry panel:

- in the 1XN100 video kit, the entry panel has a single button with RFID/MIFARE access control.

- in the 1NX300 video kit, the entry panel has a numeric keypad.

The system's main features:

- high-definition video signal;- full-duplex communication;- expandable to up to 4 entry panels- simplified configuration and installation;- also ideal for existing wiring and renovations.

The compoenents of the Xentry videokits are:

- art. XN100: door station with 1 call button and RFID/MIFARE. Click here for more info

- art. XN300: door station with numeric keypad. Click here for more info

- art. XN700: 7" videointercom. Click here for more info

- art. PRSXN: power supply. Click here for more info

- art. RLXN: additional relay. Click here for more info

Click HERE to watch the tutorials for Xentry

Click HERE to watch the clip Xentry

IP EVO is the innovative Farfisa technology, an IP solution dedicated to multi-user complexes (but also great in little implants) that takes advantage of an innovative approach for the video door phone market, in order to respond to precise needs of the highest level from a functional and safety point of view.

The system is basically made up of

- door station Connecto series (art. TD1000CN) or Alba series (modular composition with art. CV1000AB)

- the dedicated IP EVO app

- specific video intercoms (art. SE4000) and/or mobile device such as smartphones, tablets and Alexa...

The technology is based on the WebRTC protocol, expressly conceived for the best audio-video quality, in fact it offers various advantages that represent its absolute strengths:

very high quality of the video signal thanks to the 5MP camera
excellent audio, totally free of echo, delay or latency
top IT cybersecurity guaranteed
dedicated image encryption chip, AWS server cloud (Amazon Web Services) developed and managed by Farfisa

For the end-user multiple access ways available: IP EVO app, PIN code, QR (also temporary), RFID.

The pushbutton panels have 5Mpx camera, face focus, multilingual voice prompt.

Connecto door station has a 316L stainless steel plate with flush mounting, Skill Alexa available. It is designed for mounting an RFID access control module, but also allows access via QR code or advanced systems such as NFC and Apple Wallet. It can be connected to the Internet through various modes: Ethernet or WiFi. In the near future, the totally "stand alone" version with LTe/4G connectivity will also be available. Alba door station has anodised aluminium plate and allows modular compositions through additional button module art. CT2138AB, for installations with few users and reduced dimensions of the door station.

But the revolution of this technology lies in the possibility for the installer or condominium administrator to add, remove and modify system users, modify the access PINs associated with the users or associate them with certain time slots or specific periods of time, conveniently and remotely through the IP EVO app.

The IP EVO system is now complete with the full web concierge for 1 user (art. CNPDX1) or for 5 users (art. CNPDX5).

The possible applications are varied: large complexes such as student residences, residences and holiday homes...

Click HERE to watch the IP EVO video clip

Click HERE to download the IP EVO system guide

Click HERE to watch the 3 video tutorials

Click HERE to download the Cybersecurity brochure

two wires Pluggy Plus

More and more!!

The Pluggy Plus 2-wire system is the fastest and safest way to have an excellent guaranteed video door phone system signed by Farfisa.

It is the ideal solution for single-family systems: the Pluggy 1SEPG+ videokit is complete and ready for the installation, made up of high-level dedicated elements for top design, technology, usability and installation, without neglecting a valid solution for expandibility. The 1SEPG+ videokit consists of: monitor SEM7PG that is a 7" touch screen internal unit Wifi connected + external unit on Alba aesthetics + power supply, expandable up to 20 users and integrable with CCTV cameras.

The SEM7PG monitor on a new captivating design and Wifi connected, it is hands-free, with 7" LCD screen, menu interface with OSD, touch buttons and LED illuminated icons for door opening, conversation, intercommunication and additional functions. Signalling LED for open door and ringtone exclusion.

The external unit, also dedicated, is on the Alba aesthetic line with wide-angle camera, set up for up to 4 call buttons, offers a voice prompt that can be activated. An only door panel for each system. For the expansions further 4 users, it is available the additional call module art. CTPG, to be joint to the entry door panel included into the videokit. Up to 2 CTPG modules each system.

As integration within the apartment, in order to add further video door entry units as "slave" elements, it is necessary to use the SES7PG monitor. An audio handset is also available, the SEIPG intercom, an additional dedicated "slave" element, which allows the audio-only service inside an apartment of the system, allows the intercom inside the apartment.

CLICK HERE to download the updated depliant

CLICK HERE to download the technical manual

Two wires - Duo

The Duo System 2-wire non-polarized digital video door entry system continues to evolve. In fact, the Duo network integrates with the IP opening new frontiers without borders, with top cybersecurity.

The new WiFi connected monitor art. SE4272 allows the user to make video intercom calls to mobile devices, thanks to the IP EVO app.

The advent of the GW2IP gateway allows for enviable performance on the complete installation, allowing advantages for the entire system.

The entrance panels, like all the other elements belonging to this technology, are powered directly by the 2-wire bus, therefore the installation can be further optimized. The maximum number of users is 20,000, which can be reached thanks to the separator art. 2231Q. Further performances, more and more requested and therefore enhanced: thanks to the modulator, integrations with video surveillance systems are possible, reaching a level unthinkable until yesterday. Important support for the installer and user are given by Bluetooth technology.

Here we summarize the peculiar characteristics of the Duo system:

- Up to 20,000 users reachable

- Video calls on smartphones through the GW2IP gateway module

- true 2 wires

- programming via Bluetooth

- Entry door stations: Alba, Hero, Solvo, Agorà (powered directly by 2-wire bus)

- Indoor stations: Astro, Sette, Exhito (of which Sette is also WiFi)

- Doorkeeper exchanger

- open smart integration with videosurveillance systems

- Integrations with video surveillance and telephone systems

- Quick and easy mounting

Download here Duo catalogue

Download here gateway brochure

Download here cybersecurity brochure

Download here Duo technical manual

FN4000

DF6000

Reduced Wiring

Conventional Wiring

wireless - Mycom

A practical, fast and effective solution for access control without wiring and without distance limits is MYCOM, with GSM 4G technology.

Only an external unit (art. AB4G) and a power supply are needed to obtain a complete and reliable residential communication system without wiring. The call is made from the entry panel with traditional button modules or digital keypad and is transmitted to the landline or mobile telephone to the relevant numbers programmed in an appropriate sequence. Whoever answers the phone can communicate with the visitor and manage access.

Programming and updates can be carried out completely remotely. Available functions: CLIP, self-ignition, office function (automatic lock opening upon answering). Through an SMS the owner can be notified in the event of an event recording at the entrance (alarm function).

Several entry panels are allowed (each with its own SIM) and multiple openings, for example the door and gate, are managed separately.

The Alba range with 4G technology is compatible and can be integrated with all Alba modules and accessories.

Possible applications: apartment buildings without internal stations for distance or savings, villas with long distances between gate and building, B&Bs, car parks, night pharmacies, SOS, gates on restricted traffic zones...

Click here to download the MYCOM brochure

Click here to watch the clip for Mycom applications

IP - Farfisa IP Way

Farfisa IP Way is the new way to design and make video intercom installations that exploits TCP/IP data net: IP based products communicate anyway without compatibility limits, but the typical functions are easily activated, even remotely through specific devices or apparatus already daily used as PC, smart phones or tablets. Farfisa IP Way offer is new but already it has evolved. Simple and complete, the system meets the growing demand: you can add to AgoràIP door station -aesthetically and functionally identical to a traditional push-button panel where you can generate a SIP video call to internal devices, you can also join to the door station a specific ZHeroIP monitor. Therefore it results a complete system where all the advantages of digital IP technology are available and also where the typical easiness of a traditional video intercom system (look, ergonomic use, easiness of the monitor) is guaranteed high level, we are talking about the graphic interface, soft touch keys, hand-free, ESP audio system). If you choose a system without a traditional internal station, you can have the maximum simplicity of installation that means just the mounting of door station, thanks to the applications for smart phones and tablet or a wide range of VoiP land telephones compliant that can receive the call.

The applications and areas of use can vary greatly: multi-user residential estates, industrial premises or professional offices. Farfisa IP Way allows for the simple but secure management of calls and access control from remote locations. A modern and unthinkable solution until today.
